12 Overview of parameters
Maschinenfabrik Reinhausen 2014 1492374092/04 EN TAPCON® 260
Parameter Setting range Factory setting Current setting
U< regulator 2 34...160 V 60.0 V
U< regulator 2 60...100 % 60 %
U> regulator 2 34...160 V 140.0 V
U> regulator 2 100...140 % 140 %
U ref for regulator 2 49...140 V 100.0 V
Configuration > Transformer data
Primary voltage 0...9,999 kV 0 kV
Primary current 0...9,999 A 0 A
Secondary voltage 57...125 V 100.0 V
Current transformer connec-
tion
Unknown; 0.2 A; 1 A;
5 A
Unknown
Transformer circuit See [► 87] 0 1PH
Configuration > General
Display %/ A On/Off Off
Display dark On/Off On
Display kV / V kV/V V
COM1 setting 9.6 kilobaud; 19.2 kilo-
baud; 38.4 kilobaud;
57.6 kilobaud
57.6 kilobaud
R/L pulse duration 0...10 s 1.5 s
IO1-X1:23/24 See see connection dia-
gram
IO1-X1:25/26 See
IO1-X1:31 See
IO1-X1:33 See
Motor runtime 0...30 s 0.0 s
Regulator ID - 0000
Language See [► 40] English
Network address 0.0.0.0...25525525525
5
-
Network mask 0.0.0.0...25525525525
5
-
Time server address 0.0.0.0...25525525525
5
-
Gateway 0.0.0.0...25525525525
5
-
IED name - -
Configuration > Parallel operation
Blocking 0.5...20 % 20.0 %
CAN address 0...16 1
Error message 1...99 s 10 s
ParErrorIfAlone On/Off Off
