3 Product description
Maschinenfabrik Reinhausen 201422 2374092/04 ENTAPCON® 260
Card Default/option Max. number
AN Option 1
AC Option 1
AD Option 1, optional with extension
module
CIC Option 2
CPU Standard 1
IO Standard 1
MI Standard 1
SU Standard 1
UC Standard 3, 4 (for SID)
Table 6: Assemblies
The functions of the assemblies are described in the following sections. You
can find more information about the assemblies in the Technical data
[► 152] section.
Power supply
The wide range power supply (SU card) supplies the device with power. De-
pending on configuration, the device is equipped with one of the following
variants:
▪ SUH-P: Rated input voltage 100...240 V AC or 88...353 V DC (input volt-
age range 88...264 V AC, 88...353 V DC)
▪ SUM-P: Input voltage 36...72 V DC
▪ SUL-P: Input voltage 18...36 V DC
Figure 8: SUH-P card
3.5.5.1
