Muratec F-315 Field Engineering Manual

3-77
Memory Switch 64 – Remote reception and TAD interface
Switch
Initial
Setting
Adjust Usage/Comments
7 0 CNG detect period after TAD
begins recording ICM
Sets the period during which CNG is detected after
the TAD begins recording incoming message.
Switch 7 6 5 4 Time
0 0 0 0 0 sec
0 0 0 1 10 sec
6 0 0 0 1 0 20 sec
0 0 1 1 30 sec Initial setting
0 1 0 0 40 sec
0 1 0 1 50 sec
0 1 1 0 60 sec
5 1 0 1 1 1 70 sec
1 0 0 0 80 sec
1 0 0 1 90 sec
1 0 1 0 100 sec
1 0 1 1 110 sec
4 1 1 1 0 0 120 sec
1 1 0 1 130 sec
1 1 1 0 140 sec
1 1 1 1 150 sec
3 0 CNG detect period after TAD
answers
Sets the period during which CNG is detected after
the TAD answers an incoming call.
Switch 3 2 1 0 Time
0 0 0 0 0 sec
0 0 0 1 10 sec Initial setting
2 0 0 0 1 0 20 sec
0 0 1 1 30 sec
0 1 0 0 40 sec
0 1 0 1 50 sec
0 1 1 0 60 sec
1 0 0 1 1 1 70 sec
1 0 0 0 80 sec
1 0 0 1 90 sec
1 0 1 0 100 sec
1 0 1 1 110 sec
0 1 1 1 0 0 120 sec
1 1 0 1 130 sec
1 1 1 0 140 sec
1 1 1 1 150 sec
Incoming rings
CNG detection is active CNG detection is active
Silent detection is active
Silent detection time
TAD plays Outgoing message
TAD records Incoming message
(Adjusted by Memory switch 64, bit 0-3)
(Adjusted by Memory switch 64, bit 4-7)
(Adjusted by Memory switch 63, bit 0-3)
(Adjusted by Memory switch 63, bit 4-7)
