5-67
5-67
SENSOR OPEN1
1.
Re
mov
e the Cover option.
(See page 5-20)
2.
Re
mov
e the Cover shield.
(See pa
ge 5-20)
3.
Re
mov
e the Cover back.
(
See page 5-32)
4.
Re
mov
e the Sens
or stopper.
5.
Dis
connect t
he con
nector of S
ensor
, and then re
move the Sensor O
PEN1.
OPEN1
Sensor stopper
