3-106
3.14.3 Key Panel Test
1.Press<Setting>,<*>,<1>,<1>,thenselect[PanelTest].
2.Aseachbuttononthekeypadispressed,arepresentativenameasshowinthefollowingtablewillbedis-
played.
Key Indication in LCD Key Indication in LCD
Copy Copy Personal Mode Personal
Scan Scan Job Confirm /Fax
Cancel
Job Confirm /Fax Cancel
Fax Fax Reset Reset
Print Print Numeric keys 1 to
10,*,#
Tenkey1to0,*,#
My MFP My MFP Stop Stop
Screen 1 to Screen4 Screen 1 to Screen4 Start Start
Setting Settings
EnergySave EnergySave
Login Login
3.Press<Stop>twicetocompletethekeypaneltest.
3.14.4 SRAM Check
ThismodeisusedtotesttheSRAMmemorywhereuserprogrammedparameterssuchasdate,time,TTI,
etc are stored.
TheAllRAMClearerasesallusersettingsandresetsallmemoryswitches,machineparametersandunique
switchestofactorydefaults.
1.Press<Setting>,<*>,<1>,<1>, then select “SRAM Check”.
2. Press <Start>.
Thedataarewrittento,thenreadfromeachaddress.Theresultsareshowninthedisplay.Iftheread/
writetestissuccessful,thedisplaywillshow“OK”.
Ifsomeportionoftheread/writetestfails,thedisplaywillshow“NG”withtheaddressandthedataname.
3.Press[Close]tocompletetheSRAMCheck.
