Muratec MFX-2550 Field Engineering Manual

2-8
2.3.3 Development
TonerisappliedtotheinvisiblestaticimageontheDrumandatonerimageiscreatedonthesurface.
Toner agitator
Toner supply roller
Developing roller
Drum
Part Name Function
1 Toner Agitator Agitates toner.
2 Toner supply Roller
Transportsthetonertothedevelopingroller.
3 DevelopingRoller CarriesthetonertotheDrumsurfacefordevelopment.
4 Drum ExposedbyLEDlighttocreateaninvisibleimageand
rotatestocarrythedevelopedimagetothepapersurface.
2.3.4 Image Transfer
ImagetransferistheprocessoftransferringthetonerimagecreatedontheDruminthedevelop-
ingprocesstopaper.IntheRollerImageTransfer,thereislittlegenerationofozoneduetocorona
discharge.Also,thereisnobluroftonerbecausethepaperisalwayspressedbytheDrumandthe
Image Transfer Roller.
High voltage unit - output
PC Drum
Image transfer roller
