Muratec MFX-2550 Field Engineering Manual

5-15
ROLLER EXIT ADF
1. RemovetheGuideinnerA[1].(SeeGUIDEINNERA)
2. RemovetheSpringPearth.(SeeROLLERFEED)
3. OpentheGuideinnerB[2].
4. RemovetwoE-rings[3],oneBearing[4],andoneGear270.5oneway[5].
[
3
]
[
3
]
[
2
]
[
6
]
[
5
]
[
1
]
[
4
]
5. RemovetheROLLEREXITADF[6]byslidingit.
[
6
]
