5-89
CLUTCH
1. RemovetheCoverconnect.(SeeCOVERCONNECT)
2. RemovetheCoveroption.(SeeCOVEROPTION)
3. RemovetheCovershield.(SeeCOVERSHIELD)
4. RemovetheCoverback.(SeeCOVERBACK)
5. RemovetwoStopperrings[1].
6. Disconnecttwoconnectors[2].
7. RemovetwoCLUTCHes[3].
[
3
]
[
2
]
[
3
]
[
2
]
[
1
]
[
1
]
