Muratec MFX-2550 Field Engineering Manual

5-58
ASSY COVER TOP
1. RemovetheCoverplaten.(SeeCOVERPLATEN)
2. Removesixscrews[1],thenremovetheASSYCOVERTOP[2].
[
1
]
[
1
]
[
1
]
[
1
]
[
1
]
[
2
]
[
1
]
Caution
WhenremovingtheASSYcovertop,becarefulnottobreakthePane.
