Muratec MFX-2550 Field Engineering Manual

5-88
SOLENOID
1. RemovetheCoverconnect.(SeeCOVERCONNECT)
2. RemovetheCoveroption.(SeeCOVEROPTION)
3. RemovetheCovershield.(SeeCOVERSHIELD)
4. RemovetheCoverback.(SeeCOVERBACK)
5. Removeonescrew[1],thenremovetheBracketSLND[2].
6. Disconnecttheconnector[3]andcuttheCabletie[4].
7. Removeonescrew[5],thenremovetheSOLENOID[6].
[
6
]
[
5
]
[
4
]
[
2
]
[
1
]
[
3
]
