GUIDE INNER A
1. RemovetheTraydocument.(SeeTRAYDOCUMENT)
2. RemovetheCoverTXsideB.(SeeCOVERTXSIDEB)
3. RemovetheCoverTXsideF.(SeeCOVERTXSIDEF)
4. Removeonescrew[1].
5. CuttheCabletie[2].
6. Removetwoscrews[3],andremovetheAPSbracket[4].
7. Removetwoscrews[5].
8. Releaseonehook[6],thenremovetheGUIDEINNERA[7].
[
2
]
[
1
]
[
5
]
[
5
]
[
7
]
[
6
]
[
3
]
[
4
]
