5-47
SENSOR TXIL / DS1
1. RemovetheCoverTXB.(SeeCOVERTXB)
2. Disconnecttwoconnectors[1],thenremovetheSENSORTXIL[2],andSENSORDS1[3].
[
1
]
[
1
]
[
2
]
[
3
]
