Muratec MFX-2550 Field Engineering Manual

5-118
MOTOR (STEPPING)
1. RemovetheCoverconnect.(SeeCOVERCONNECT)
2. RemovetheCoveroption.(SeeCOVEROPTION)
3. RemovetheCovershield.(SeeCOVERSHIELD)
4. RemovetheCoverback.(SeeCOVERBACK)
5. RemovetheChassisFBS.(SeePCBCONNECTLPH)
6. RemovetheCoverleft.(SeePCBNCU)
7. RemovetheTraypaperexit.(SeePCBCONNECTLPH)
8. Disconnecttheconnector[2]fromthePCBLPH[1].
[
2
]
[
1
]
9. Removethetwoscrews[3],thenremovetheMOTOR(STEPPING)[4].
[
3
]
[
3
]
[
4
]
