Muratec MFX-2550 Field Engineering Manual

5-48
MOTOR (STEPPING)
1. RemovetheDADFcoverTX.(SeeDADFCOVERTX)
2. RemovetheDADFframescanner.(SeeDADFFRAMESCANNER)
3. RemovetheDADFguideinnerA.(SeeDADFGUIDEINNERA)
4. RemovetheDADFguideinnerBequippedwithDADFDRIVE.(SeeDADFGUIDEINNERBequipped
withDADFDRIVE)
5. RemovetheStaydrivesensorandClutch.(SeeCLUTCH)
6. Removethethreescrews[1],thenremovetheFramemotor[2].
[
1
]
[
1
]
[
1
]
[
2
]
7. RemovetheGear35A[3].
8. Removethetwoscrews[4],thenremovetheMOTOR(STEPPING)[5].
[
3
]
[
4
]
[
4
]
[
5
]
