Muratec MFX-2550 Field Engineering Manual

5-128
ASSY SHAFT JOINT (2nd CST)
1. RemovethePrintercassette2ndfromthemainunit.(SeeSENSORPES2)
2. Pull out the Cassette 2nd. (See SENSOR PES2)
3. RemovetheRollerfeed2nd.(SeeROLLERFEED2ND)
4. RemovethePlateframeB[1].(SeePLATEFRAMEB)
5. Removethreescrews[2],thenremovetheHoldergear2nd[3].
6. RemoveoneE-ring[4],thenremovetheASSYSHAFTJOINT[5].
[
3
]
[
2
]
[
2
]
[
2
]
[
5
]
[
4
]
[
1
]
