5-38
ROLLER REGIST
1. RemovetheDADFframescanner.(SeeDADFFRAMESCANNER)
2. RemovetheDADFguideinnerA.(SeeDADFGUIDEINNERA)
3. TurntheDADFguideinnerA[1]overandremoveoneE-ring[2].
4. RemoveBearingD6[3],thenremovetheROLLERREGIST[4].
[
2
]
[
3
]
[
1
]
[
4
]
