Muratec MFX-2550 Field Engineering Manual

5-37
9. Disconnectoneconnector[9].
10.RemoveoneSR4[10],thenremovetheClutch[11].
11.RemoveoneE-ring[12],thenslidetheBearingD68[13]totheouterend.
12.RemovetheDADFGUIDEINNERA[14]byliftingitup.
[
14
]
[
9
]
[
10
]
[
11
]
[
12
]
[
13
]
