Muratec MFX-2550 Field Engineering Manual

5-105
ASSY INTERLOCK
1. RemovetheCoverconnect.(SeeCOVERCONNECT)
2. RemovetheCoveroption.(SeeCOVEROPTION)
3. RemovetheCovershield.(SeeCOVERSHIELD)
4. RemovetheCoverback.(SeeCOVERBACK)
5. RemovetheChassisFBS.(SeePCBCONNECTLPH)
6. RemovetheCoverleft.(SeePCBNCU)
7. RemovetheTraypaperexit.(SeePCBCONNECTLPH)
8. OpentheCoverjamaccess[1].
9. Removeonescrew[2],thenremovethePlateupperFG[3].
10.Removevescrews[4],thenremovethePlateFGexit[5]andtheFrameupper[6].
11.Disconnecttheconnector[7]andremovetheASSYINTERLOCK[8].
[
2
]
[
3
]
[
4
]
[
4
]
[
6
]
[
5
]
[
4
]
[
7
]
[
8
]
[
4
]
[
4
]
[
1
]
