Muratec MFX-2550 Field Engineering Manual

5-28
DADF COVER TX
1. RemovetheCoverTXB.(SeeCOVERTXB)
2. RemovetheCoverTXF.(SeeCOVERTXF)
3. Removethetwoshafts[1],thenremovetheDADFCOVERTX[2].
*WhenremovingtheDADFCOVERTX,liftitupslightlyandremoveitfromtheshaftonthefront.
4. Removeonescrew[3].
[
1
]
[
1
]
[
2
]
[
3
]
