Muratec MFX-2550 Field Engineering Manual

5-33
PCB R-SCANNER
1. OpentheDADFcoverTX.(SeeDADFFRAMESCANNER)
2. RemovetheDADFframescanner.(SeeDADFFRAMESCANNER)
3. Removethethreescrews[1],thenremovethePlateshieldDADFA[2].
4. Removethelmharness[3].
5. Removethefourscrews[4].
6. RemovethePCBR-SCANNER[5].
[
4
]
[
4
]
[
4
]
[
4
]
[
3
]
[
1
]
[
1
]
[
2
]
[
1
]
[
5
]
