5-41
ASSY ROLLER SEPARATOR
1. RemovetheDADFcoverTX.(SeeDADFCOVERTX)
2. Removethevescrews[1],thenremovetheGuideouterA[2].
3. RemoveoneE-ring[3].
4. RemoveoneE-ring[4],thenremovetheGear26[5]andBearingD68[6].
5. RemovethefourE-rings[7].
6. RemovethetwoBearingsD6[8],andmovethetwoBearingsD6[9]towardthecenter.
[
4
]
[
5
]
[
6
] [
8
]
[
3
]
[
7
]
[
9
]
[
9
]
[
7
]
[
1
]
[
1
]
[
1
]
[
1
]
[
1
]
[
7
]
[
7
]
[
8
]
[
2
]
7. RemovetheASSYROLLERSEPARATOR[10].
