Muratec MFX-2550 Field Engineering Manual

5-36
DADF GUIDE INNER A
1. OpentheDADFcoverTX.(SeeDADFFRAMESCANNER)
2. RemovetheDADFframescanner.(SeeDADFFRAMESCANNER)
3. Cutthetiewrap[1].
4. Removethefourscrews[2],thenremovethePlateshieldDADFC[3].
5. DisconnectallPCBRADF[4]connectors.
6. Removeonescrew[5].
7. Removethefourhooks[6]ontheGuideharness,thenremovetheharnessfromtheGuideharness.
[
1
]
[
4
]
[
5
]
[
6
]
[
3
]
[
2
]
[
2
]
[
2
]
[
2
]
[
6
]
[
6
]
[
6
]
8. Removeonescrew[7],thenremovetheGuideharness[8].
[
7
]
[
8
]
