Muratec MFX-2550 Field Engineering Manual

5-108
ROLLER EXIT (MFX-2550 only)
1. RemovetheCoverconnect.(SeeCOVERCONNECT)
2. RemovetheCoveroption.(SeeCOVEROPTION)
3. RemovetheCovershield.(SeeCOVERSHIELD)
4. RemovetheCoverback.(SeeCOVERBACK)
5. RemovetheChassisFBS.(SeePCBCONNECTLPH)
6. RemovetheCoverleft.(SeePCBNCU)
7. RemovetheTraypaperexit.(SeePCBCONNECTLPH)
8. OpentheCoverjamaccess.(SeeASSYINTERLOCK)
9. RemovetheFrameupper.(SeeASSYINTERLOCK)
10.RemovetwoE-rings[1],thenremovetheBearingD69[2].
11.Loosentwoscrews[3]intheGuidefuser.
12.RemovetheROLLEREXIT[4]byslidingit.
[
3
]
[
3
]
[
1
]
[
1
]
[
2
]
[
4
]
Important
WhenassemblingBearingD69,makesureitisalignedwiththenotchintheFrameupper.
