Muratec MFX-2550 Field Engineering Manual

5-79
PCB NCU
1. Removetwoscrews,thenremovetheCoveroption.(SeeCOVEROPTION)
2. OpentheCoverfront[1].
3. Removeonescrew[2].
4. RemovetheCoverleft[3]whilepressingdownonthetwohooks.
[
1
]
[
2
]
[
3
]
5.Removeonescrew[4]andreleasetheCable-clamp[5]ontheharness.ThenpulloutthePlateNCU1[6].
6.Disconnecttheconnector[7]andremovethePCBNCU[8].
[
4
]
[
5
]
[
6
]
[
7
]
[
8
]
