Muratec MFX-2550 Field Engineering Manual

5-78
PCB MAIN
1. RemovetheCoverconnect.(SeeCOVERCONNECT)
2. RemovetheCoveroption.(SeeCOVEROPTION)
3. RemovetheCovershield.(SeeCOVERSHIELD)
4. RemovethePCBIS.(SeePCBIS)
5. Removetwoscrews[1],thenremovethePlatemainB[2].
6. Removeonescrew[3],thenremovetheBracketlime[4].
7. DisconnectallPCBMain[5]connectors.
8. Removeninescrews[6],thenremovethePCBMAIN[5].
[
6
]
[
6
]
[
6
]
[
6
]
[
6
]
[
6
]
[
6
]
[
6
]
[
6
]
[
5
]
[
1
]
[
1
]
[
3
]
[
4
]
[
2
]
