Muratec MFX-2550 - Mirror C;D

5-35
MIRROR C/D
1. OpentheDADFcoverTX.(SeeDADFFRAMESCANNER)
2. RemovetheDADFframescanner.(SeeDADFFRAMESCANNER)
3. RemovetheCoverupperscanner.(SeeCOVERUPPERSCANNER)
4. ReleasethesixMirrorclamps[1],andremoveMIRRORC[2]andMIRRORD[3].
[
