Muratec MFX-2550 Field Engineering Manual

5-74
5.2.5 PCB section
PCB PDL
1. RemovetheCoverconnect.(SeeCOVERCONNECT)
2. RemovetheCoveroption.(SeeCOVEROPTION)
3. RemovetheCovershield.(SeeCOVERSHIELD)
4. Removeonescrew[1].
5. RemovetwoPCB-PS[2].
6. Disconnecttheconnector[3]andremovethePCBASSYPDL[4].
[
4
]
[
1
]
[
2
]
[
2
]
[
3
]
7. Removefourscrews[5]andremovethePCBPDL[6].
[
6
]
[
5
]
[
5
]
[
5
]
[
5
]
