Muratec MFX-2550 Field Engineering Manual

5-133
Printer registration (side)
A
A
Test pattern H
AdjustsothatwidthAonthetestpatternCheckeredoutputfallswithinthefollowingrange.
Standard Setting Range
10 ± 1.8 (mm)
–12.8 to 12.7 (mm)
(0.6773 mm step)
Adjustment procedure
1.Loadletterpapertothecassetteortrayyouwanttoadjust.
2.UsetheUniqueSwitch52toadjusttheprintingmarginto0mm.(bit0,1 0)
3. Printout the test pattern “Ladder”. (See “3.12.2 Printer Test”.)
4.CheckwidthAonthetestpatternLaddermeetsthespecications.
IfwidthAfallsoutsidethespeciedrange,performfollowingstepstomaketheadjustment.
5.Tousethe“Printerregistrationmode,”pressSetting>,<*>,<4>,<3>themargin.
6.Afteryouhavenishedtheadjustment,youmustreenterthesettingofUniqueSwitch52,you
changed in step 2.
