1-2
21
22
23
14
15
16
17
18
19
20
24
No. Name Description
14
Platencover Thisholdsdownthedocument.
15 Document glass Load the document here aligned to the top left of the glass.
16 ADF glass
Thisiswhere documentsloadedintheADF(AutoDocumentFeeder)
are scanned.
17 Paper exit tray
Thecopiedorprintedpaperexitswiththeprintedsidedowninthistray.
18 Mainpowerswitch ThisswitchisusedtoturnthemachineONandOFF.Normally,leave
thepower ON.Turnit OFFifyoudonot use themachinefora long
periodoftimeormoveit.
19 Powerjack Connectthepowercordhere.
20 Networkconnector Connect the LAN cable here.
21 USB port Connect the USB cable here.
22 Phone jack Connect a handset here.
23 External phone jack
Connectanexternalphone(suchasanansweringmachine)here.
24 Telephone line jack Connect the modular cable here.
