Handling the printer RJ-900X series OPERATION MANUAL
4-24
2. Performs Initial Adjust Print.
a. Press the [Enter] key on Operation panel.
Feed Length: 250 mm is displayed on Operation panel.
TIP
The length of media that is fed (feeding length) for initial adjustment printing is normally set at 250 mm.
If you increase the feeding length, the accuracy of the Media feed compensation improves.
To change the feeding length, press the [+] key or [-] key on Operation panel to change the set value.
b. Press the [Enter] key on Operation panel.
Printing is displayed on Operation panel.
Starts initial adjustment printing.
When the initial adjustment printing is complete, the printer enters the Normal condition.
c. After the initial adjustment printing, cut the media.
4.6.3 Cut media
3. Measure the distance between the two pluses (+) in the initial adjustment print using a ruler.
No. Name
1
Feeding length
2
Media feeding direction
2
1
1
