VJ-1628X OPERATION MANUAL Before using
3.7 Print quality adjustment 129
• An micro adjust print pattern is printed.
(Starts printing after warming up is complete.)
• For the micro adjustment pattern, the same patterns will be printed on both sides and center of
the media.
4. Check the print results on both sides and center of the media and select the number that looks most
aligned between 1 and 7.
• “6” is selected in the next printing sample.
• “4” represents the current setting value.
• When the line is aligned, the bold line on its left side does not have a white vertical line in the
middle.
1234567
Pattern name
Current Print Mode
Q3/Q4
B
Not adequate Adequate
Not adequate
To Next Page
