VJ-1628X OPERATION MANUAL Handling the printer
4.2 Media 167
2. Performs Initial Adjust Print.
a. Press the [Enter] key on Operation panel.
• “Feed Length: 250 mm” is displayed on Operation panel.
TIP
The length of media that is fed (feeding length) for initial adjustment printing is normally set at 250 mm.
If you increase the feeding length, the accuracy of the Media feed compensation improves.
To change the feeding length, press the [+] key or [-] key on Operation panel and change the set value.
b. Press the [Enter] key on Operation panel.
• “Printing” is displayed on Operation panel.
• Starts initial adjustment printing.
• When the initial adjustment printing is complete, the printer enters Normal.
c. After the initial adjustment printing, cut the media.
4.4.3 Cutting media
3. Measure the distance between the two pluses (+) in the initial adjustment print using a ruler.
No. Name
1Feed Length
2 Media feeding direction
2
1
1
