Suspension and wheels
F
- 6-
Front wheel bearing substitution
Remove the wheel spindle utilising the special tool as
shown in the figure.
Special tool N. 8000B4412
Front wheel bearing check
Preliminary operations (only for F4 RR):
- Fit the axle on the front wheel.
- Turn in and bring the threaded bushing (Code no.
80A0A3469) into contact with the wheel spindle, tigh-
tening it by hand.
With the wheel spindle still mounted to the wheel,
rotate the wheel to check that the bearings are not pit-
ted and rotate with a smooth action. Check also for
axial (A) and/or radial (B) movement. If either condition
is verified, substitute the bearings.
A
B
Utilise the special tool to extract the bearings. To
assemble the tool, it is necessary to remove the screw
(1) and extract the wheel spindle (2). Remove the nut
(3) and then the flange (4).
Before substituting the bearings as indicated
above it is advisable to remove the brake
discs as indicated in chapter H “Brakes” to
avoid damaging them.
Special tool N. 8000B4416
2
4
3
1
