Suspension and wheels
F
- 7-
Introduce the extractor until the internal ring of the
bearing is hooked up. Introduce the wheel spindle and
screw and and manually block them.
Mount the flange, spacer ring and nut utilising a 14 mm
spanner and a 27 mm spanner and extract the bearing
as shown in the figure.
Operate in the same way on both bearings.
NOTE
Check that the ends of the aluminium spacer and the
seats of the bearings on the wheels are not scored or
marked.
