Suspension and wheels
F
- 27 -
Front suspension adjustment
(F4 RR MY12)
Refer to values contained in the table to adjust front
suspension.
Type of set-up
On road On race track
Spring preload 12 turns 12 turns
Rebound damping 9 clicks 8 clicks
Compression damping 11 clicks 11 clicks
F4 RR MY12
Rebound damper
Rebound damper
Spring preload
Compression damper
Spring preload
Compression damper
Adjustments contained in the table
must be carried out from initial referen-
ce positions:
- Spring preload: Turn counter-clockwi-
se to end stroke.
- Rebound damping: Turn clockwise to
end stroke.
- Compression damping: Turn clockwise
to end stroke.
Spring
preload
NOTE
