Suspension and wheels
F
- 50 -
Check for eventual axial play of the bolt holes of the
connecting rod (2). Substitute if worn.
2
Rocker arm assembly overhaul
Remove the anti-dust seal (1).
Check the condition of the roller bearings and if it is
necessary to substitute them, utilise an extractor as
shown in the figure.
1
Rocker arm assembly removal
Remove the special screw (1) that fixes the compen-
sator assembly of the rear suspension to the mono-
arm fork. Extract the complete compensator assembly.
1
