11 Remote control EFA-200/-300
11-8
11.4.1 Measurement settings
Note: When you use the EFA-TS PC software to remote control the
EFA, note the following particulars:
In “Exposure STD” mode, you can select the standard to be
applied and the measurement range by remote control using the
EFA-TS software.
If you select a standard or “no standard” on the EFA manually,
the EFA-TS remote control function for setting the standard and
the measurement range will be disabled.
✓ Remote operation is activated.
Global parameters
Write / action
commands
Read commands Range of values of p Meaning or units
of p
Select / read operating mode
C142 <p> C143 0 = Field strength
1 = Exposure STD
3 = Spectrum FFT
4 = Harmonic
Analysis
Select / read B-field measurement range
C138 <p> C139 0 = AUTO
1 = 100 nT
2 = 316 nT
3 = 1 µT
4 = 3,16 µT
5 = 10 µT
6 = 31.6 µT
7 = 100 µT
8 = 316 µT
9 = 1 mT
10 = 3.16 mT
11 = 10 mT
12 = 31.6 mT
Table 11-2 Remote control commands, global parameters
