NARDA EFA-200 - Brief Description; Frequency Range; Result Display

12 Specifications EFA-200/-300
12-16
12.5.1 Brief description
• Measurement of the magnetic flux density or electric field strength based
on spectrum analysis through a Fast Fourier Transformation.
• Determination of the exact fundamental frequency by entering
an approximate value
• Measurement of the field strength of the fundamental and harmonics.
12.5.2 Frequency range
12.5.3 Result display
The number of displayable harmonics is limited by the ratio of the selected
fundamental frequency and the available frequency range.
Frequency of fundamental,
selectable
10 Hz…500 Hz
Resolution 0.1 Hz
10 Hz…10 kHz
Resolution 0.1 Hz
Frequency range, internal 5 Hz…2 kHz 40 Hz…32 kHz
Graphical display • Spectrum (measured value, index of
fundamental/harmonics)
• Units of decibels (dB) and reference value (T, G
or V/m)
Result list, tabular • Frequency of fundamental
• Measured value of fundamental
• Harmonic factors of 2nd to 10th harmonic
• Overall harmonic factor (not VECT PEAK)
• Noise/harmonic factor (not VECT PEAK)
