12 Specifications EFA-200/-300
12-8
Background display level due to intrinsic noise
The background display level depends on the limit value curve that is
selected.
Typical values:
Dynamic range
The dynamic range is calculated from the difference between the
measurement range limit and the intrinsic noise indication.
The dynamic range is typically > 54 dB for sine wave signals.
12.3.4 Limit value curves
Up to six limit value curves can be implemented. The following standards
are available, among others:
Note: The available curves can be updated if needed using the
“EFA-200/-300 Tools” software.
Transferring STANDARDS parameters: siehe Seite 10-8
Setting B-Field Unit E-Field Unit
(EFA-300
only)
100 cm
2
probe
(2245/90.10)
Built-in probe 3 cm probe
(2245/90.20)
BGV01
EXP1
< 2% < 4% < 3% < 2.5%
ICN98
OCCUP
< 0.4% < 2% < 1% < 5%
Standard,
selectable
• BGV01 EXP2
• BGV01 EXP1
• BGV01 2H/D
• ICN98 GNPUB
• ICN98 OCCUP
• VDE01
Unfallverhütungsvorschrift, Germany (June 2001)
ICNIRP Guidelines, April 1998
VDE 0848, Draft Stage, July 2001
