8 Setup and configure
94 NBM-550 Narda
8.5 Activating instrument options
Instrument options such as the GPS/Voice Recorder/
Conditional Logging option expand the capabilities of the
NBM-550.
Options can be subsequently ordered and must then be
activated via a provided activation code (Option Key). After
activation, the option appears under Information (see
“Information” on page 112).
Activation is conducted using the NBM-TS PC software (see
“PC software” on page 95).
To activate an option:
1. Establish a connection between the instrument and PC
(see “Working with the PC software” on page 97).
2. Start the NBM-TS software.
3. Activate the connection in the Extras menu via the
Connect icon.
4. Click on the icon for activation.
A window in which all the options are listed opens.
Active options are identified with marked check bo-
xes.
5. Click on the desired option.
The Option Code field appears.
6. Enter the activation code from the Options Passport
Document in the corresponding fields and click on
Activate.
The option is activated and can be used.
You can find other tips in the PC software's online help.
Note: The activation code of an option is linked to the serial
number of the instrument. For this reason, be sure to specify
the serial number of the NBM-550 being used when placing
subsequent orders.
