10.5 Data Logger
Narda NBM-550 109
Lower
Threshold
2)
(optional)
Lower threshold for Condition Logging (only
applies to Out of gap)
Voice Recorder
(optional)
Enable voice recording after storing measured
values: On, Off
Function keys
Unit:...
2)
Select the measured value units:
W/m
2
, mW/cm
2
, V/m, A/m
Condition
Logging
2)
Open the menu for starting conditional
recording of measured values.
Timer Logging Open the menu for starting timer controlled
recording of measured values
1) The actual duration is limited by the maximum number of 32000 intervals
per data set. For dependency of the timer duration on the selected timer
interval, see table in “Setting the recording parameters” on page 81.
2) Only displayed if EHP-50 display = off
3) Up to 32000 events can be recorded.
4) After a successful recording, the measured values can be viewed with the
Data Viewer (see “Using the Data Viewer” on page 85).
It should be noted that only the first 999 sub data sets (intervals or events)
can be displayed on the NBM-550. The NBM-TS PC software enables
complete evaluation of all data.
Function Meaning
