Native Instruments Maschine User Manual

→
The Samples are loaded into the Sound slot. A new Pattern is created in that Group and
directly loaded in the Pattern Editor (switch the Pattern Editor to Keyboard view to better
see the Pattern — see section ↑7.1.5, Group View and Keyboard View). This Pattern con-
tains the sequence data of the REX file. For each REX file you import a Pattern will be
created and added.
A REX file loaded in the first Sound slot.
4.5.2 Importing MPC Programs to Groups
MASCHINE allows you to import Drum program files (.PGM and .AKP) from the Akai MPC ser-
ies to Groups. Supported models include the MPC4000, MPC3000, MPC2000, MPC500,
MPC1000 and the MPC2500.
Supported Parameters from MPC Programs
Since MASCHINE has a different approach to handling and naming parameters, please refer to
this list to find out how MPC Program settings are being translated into MASCHINE settings.
MPC Parameter MPC500,
1000, 2500
MPC400
0
MPC2000
(XL)
MPC300
0
MASCHINE Parameter
Sample Name x x x x Sample Name
Play Mode x x − − Playback Type (ADSR,
One-shot, AHD)
Sample Level x x − − Zone Level
Sample Pan − x − − Zone Pan
Managing Sounds, Groups, and Your Project
Importing Third-Party File Formats
MASCHINE - Manual - 208

Native Instruments Maschine Specifications

General

Weight	4.85 lbs (2.2 kg)
Pads	16 velocity-sensitive pads with aftertouch
Connectivity	USB, MIDI In/Out
Software	Maschine Software
Compatibility	Mac and PC
Power Supply	USB powered
Audio Interface	No built-in audio interface
Sequencer	Yes, pattern-based sequencer
Sampling	Yes, integrated sampler
Effects	Yes, includes a variety of effects
Encoders	8 knobs with LED ring indicators
DAW Integration	Yes, works as a plugin within most major DAWs
