Native Instruments Maschine User Manual

7.5.3 Creating and Editing Modulation in the Control Lane
You can also create, select, and edit individual modulation points in the Modulation pane of the
Control Lane.
Displaying the Modulation Pane in the Control Lane
1. To see and edit modulation for parameters of a Sound, click the desired Sound in the
Sound List (left of the Pattern Editor) and click the SOUND tab in the Control area.
2. To see and edit modulation for parameters of a Group, click the desired Group in the
Group List (left of the Arranger) and click the GROUP tab in the Control area.
3. If the Control Lane is not visible at the bottom of the Pattern Editor, click the up-pointing
arrow in the bottom left corner of the Pattern Editor to show it.
4. Click the little bar icon left of the Control Lane to display the Modulation pane.
→
The Modulation pane appears.
The Modulation pane showing the modulation track for the Decay parameter (see on the left).
The Modulation pane contains following elements:
Working with Patterns
Recording and Editing Modulation
MASCHINE - Manual - 363

Native Instruments Maschine Specifications

General

Weight	4.85 lbs (2.2 kg)
Pads	16 velocity-sensitive pads with aftertouch
Connectivity	USB, MIDI In/Out
Software	Maschine Software
Compatibility	Mac and PC
Power Supply	USB powered
Audio Interface	No built-in audio interface
Sequencer	Yes, pattern-based sequencer
Sampling	Yes, integrated sampler
Effects	Yes, includes a variety of effects
Encoders	8 knobs with LED ring indicators
DAW Integration	Yes, works as a plugin within most major DAWs
