Native Instruments Maschine User Manual

7. Press NAVIGATE + pad 1 to select the AUDIO Parameter page. You can also press the
Page Left button until it turns off, since the AUDIO page is the first page of the Input
properties.
You will now see two parameters at the bottom of the left display: SOURCE (which selects
the source) and GAIN (which adjusts the level of the input).
8. Turn Knob 1 to set the SOURCE to EXT. 1.
→
Now the external audio is routed to your Sound! You can adjust the level of the incoming
signal by turning Knob 2 (GAIN).
11.2.3 Step 3: Load an Effect to Process an Input
Here we describe the procedure in Arrange view. You can also do this in Mix view — see
section ↑11.1.1, Adding an Effect.
You can now insert an Effect Plug-in into this Sound so that it processes the incoming audio.
1. At the far left of the Control area, click the Plug-in icon to display the Plug-ins of the
Sound:
The icon lights up. The Plug-in List appears nearby. Since we have chosen an empty
Using Effects
Applying Effects to External Audio
MASCHINE - Manual - 593

Native Instruments Maschine Specifications

General

Weight	4.85 lbs (2.2 kg)
Pads	16 velocity-sensitive pads with aftertouch
Connectivity	USB, MIDI In/Out
Software	Maschine Software
Compatibility	Mac and PC
Power Supply	USB powered
Audio Interface	No built-in audio interface
Sequencer	Yes, pattern-based sequencer
Sampling	Yes, integrated sampler
Effects	Yes, includes a variety of effects
Encoders	8 knobs with LED ring indicators
DAW Integration	Yes, works as a plugin within most major DAWs
