Element Description
SCALE Section
Velocity Adjusts the velocity response of the drum. Available values range
from -100.0 % to 100.0 % (default value). At zero (mid course),
the drum is played at full velocity, no matter how hard you hit the
keys (or pads). From the mid position, by turning the knob to the
right you increase the positive velocity response and make the drum
more and more sensitive to the velocities at which you hit the keys/
pads. From the mid position, turning the knob to the left as the
inverse effect: the harder you hit the key/pad, the softer the
resulting drum sound will be.
10.5.4 Tom – High
The High Tom is an acoustic tom that complements the Floor Tom. With very few parameters it
provides a wide range of tom rolls and fills.
The parameters described below are presented as they appear in the Control area (Ar-
range view). The same parameters are available in the Plug-in panel within the Plug-in
Strip (Mix view). See ↑9.4, The Plug-in Strip for more information on this.
Main Page
Element Description
MAIN Section
Engine Selects the engine used in the Tom plug-in. For more information
on the available engines, please refer to section The Toms.
Tune Adjusts the pitch of the drum played by the middle C, measured in
MIDI note numbers and cents. Available values range from 57.00
(NOTE A2) to 71.00 (NOTE B3). The default value is 57.00.
Decay Adjusts the duration of the sound’s tail, measured as a percentage.
Available values range from 0.0 to 100.0% (default: 50.0%).
Using the Drumsynths
The Toms
MASCHINE - Manual - 556
