Side-Chain Input Page
The Limiter in the Control area: Side-Chain Input page.
The Modulation page contains one parameter: Velocity.
Element Description
INPUT Section
Source Selects the audio signal you want to use as side-chain signal to control
the Plug-in. Available options are None (side-chain disabled, default
setting), the outputs of all (other) Sounds, and the outputs of all
(other) Groups.
In the menu these outputs are labeled as follows:
▪ For Groups: [Group name] (e.g., Drums)
▪ For Sounds: [Group name]: [Sound name] (e.g., Drums: Kick)
▪ In the selector display these outputs are labeled as follows:
▪ For Groups: [Group name] (e.g., Drums)
▪ For Sounds: [Group letter+number]:S[Sound number] (e.g., A1:S4 for
the Sound 4 of Group A1)
Gain
Adjusts the input level of the side-chain signal fed into the Plug-in.
Available values range from 0.00 dB to 1.00 (default: 1.00).
FILTER Section
Effect Reference
Dynamics
MASCHINE - Manual - 618
