SECTION 2 PROGRAMMING MODE
2.1 Entering the Programming Mode
The installer/system administrator can enter to the system programming mode from the Display Type
Multiline Telephone. (A maximum of two users can enter mode at the same time)
In a newly installed system, use extension port 1.
1. Press Speaker key. (Do not lift the handset)
2. Dial #
#
.
11-10 WED 1:49PM
200
Menu Dir VM:00 CL:00
Password
Figure 3-6 Entering Programming Mode Display 1
3. Dial the system password, then press Hold key to enter the Program Mode.
Password@@@@@@@@
Program Mode
Base Service OP1 OP2
Figure 3-7 Entering Programming Mode Display 2
For the details of programming, refer to the SL1100 Programming Manual. (separate issue)
2.2 Exiting the Programming Mode
1. Press Mute key several times to return to the "Program Mode" Screen.
10-01- Sys Config
Time&Date Setup |01
back Select
Program Mode
Base Service OP1 OP2
Figure 3-8 Exiting the Programming Mode Display 1
2. Press Speaker key to exit.
Program Mode
Base Service OP1 OP2
11-10 WED 1:49PM
200
Menu Dir VM:00 CL:00
Figure 3-9 Exiting Programming Mode Display 2
The system automatically saves the customer data to the memory which is backed up by lithium
battery.
SL1100 ISSUE 4.1 (R5.1)
3-4 System Start Up
