2.13 Optional Unit Mechanical Specifications
Table 5-8 Optional Unit Mechanical Specifications
Unit Width Depth Height Weight Note
IP4[ ]-MEMDB-C1 67.5 mm
(2.66 in)
32 mm
(1.26 in)
2 mm
(0.08 in)
0.01 kg
(0.3 oz)
IP4WW-VOIPDB-C1 66 mm
(2.60 in)
138 mm
(5.43 in)
18 mm
(0.71 in)
0.05 kg
(1.76 oz)
PZ-VM21 53 mm
(2.09 in)
85 mm
(3.35 in)
13 mm
(0.51 in)
0.03 kg
(1.06 oz)
IP4WW-080E-B1 160 mm
(6.30 in)
198 mm
(7.80 in)
32 mm
(1.26 in)
0.17 kg
(6.00 oz)
IP4[ ]-008E-B1 160 mm
(6.30 in)
198 mm
(7.80 in)
32 mm
(1.26 in)
0.16 kg
(5.64 oz)
IP4WW-000E-B1 160 mm
(6.30 in)
198 mm
(7.80 in)
32 mm
(1.26 in)
0.12 kg
(4.23 oz)
IP4WW-4COIDB-B1 75 mm
(2.95 in)
170 mm
(6.69 in)
18 mm
(0.71 in)
0.08 kg
(2.82 oz)
IP4WW-1PRIU-C1 160 mm
(6.30 in)
198 mm
(7.80 in)
32 mm
(1.26 in)
0.15 kg
(5.29 oz)
IP4WW-2BRIDB-C1 122 mm
(4.80 in)
168 mm
(6.61 in)
25 mm
(0.98 in)
0.09 kg
(3.17 oz)
IP4WW-CFVMS-C1 43 mm
(1.69 in)
37 mm
(1.46 in)
3.5 mm
(0.14 in)
0.01 kg
(0.35 oz)
2.14 Doorphone Interface Specifications
Table 5-9 Doorphone Interface Specifications
Item Specification
Output Impedance 600 Ω
Output Level Nominal 250 mV (-10 dBm)
Maximum Output 400 mV RMS
2.15 General Purpose/Door Unlock Relay Specifications
Table 5-10 General Purpose/Door Unlock Relay Specifications
Item Specification
Rated Voltage DC 48 V Maximum
Rated Current DC 320 mA Maximum
Contact Normally Open
2.16 External Paging Output Specifications
Table 5-11 External Paging Output Specifications
Item
Specification
Output Impedance 600 Ω @ 1 kHz
SL1100 ISSUE 4.1 (R5.1)
5-6 Specifications
