4. Loosen two screws and remove the Main-Cover.
Two screws
Hooks
Main-Cover
Figure 4-8 Removing the Main-Cover
5. Press tab A and lift the CPU support bracket.
6. Remove CPU card from the Main KSU.
CPU support
CPU card
084M-B1 at 1228M KSU
A
Figure 4-9 Removing the CPU Card
ISSUE 4.1 (R5.1) SL1100
Hardware Manual 4-5
