SECTION 5 INSTALLING THE MULTILINE TELEPHONES AND
OPTIONAL TERMINALS
5.1 Installing the Multiline Telephones
There are three types of Multiline Telephones available in the SL1100 system.
• IP4WW-12TXH-B-TEL
• IP4WW-24TXH-B-TEL
• IP4WW-24TIXH-C-TEL (IP)
5.1.1 Location of Controls
Exit Help
Flash
Clear/Back
ABC
GHI JKL MNO
PQRS TUV WXYZ
DEF
Hold
Speaker
1
23
4
56
7
89
0
㧏
Mute DND
Transfer
Handset
Exit
Alphanumeric Display
Indicator
Help
Soft key
Programmable
function keys
24T( )XH only
Dial keys
Hold
Speaker
Speaker
Flash
Transfer
DND
Mute
Clear/Back
Cursor control key
Light Sensor
Figure 2-96 Multiline Telephone (12TXH/24TXH/24TIXH (IP))
Table 2-22 Multiline Telephone Functions (12TXH/24TXH/24TIXH (IP))
Functions
12TXH 24TXH 24TIXH
Programming Keys 12
(Busy lamp field: Red-Green)
24
(Busy lamp field: Red-Green)
24
(Busy lamp field: Red-Green)
Display 24-digit x 3 lines with Backlit
Handsfree Full-duplex
Wall-Mount Kit Yes (Built-in) Yes (Optional)
SoftKeys Yes
ISSUE 4.1 (R5.1) SL1100
Hardware Manual 2-67
